DEHNguard ME/SE DC ... (FM)

  • 通用单极电涌保护器，由底座和可插拔保护模块组成
  • 直流电路专用
  • 高性能的直流切断装置DCD，可预防直流电弧造成的火灾损害
  • 在特定的应用中可以不配备额外的后备熔丝
  • 工作状态 / 故障指示
  • 使用模块释放按钮轻松更换保护模块，无需使用工具

DEHNguard M DC ACI 1250 FM

用于直流应用的模块化电涌保护器；带无电势远程信号触点。

1 Product

Part No. 972150 DG M DC ACI 1250 FM

GTIN 4013364530850, Customs tariff No. (EU): 853540, Gross weight: 652.76 g, PU: 1.00 件

Images

Additional information

2 型电涌保护器，DG M DC ACI 1250 FM
模块化，可插拔式电涌保护器
用于直流应用，宽度为 6 个模组
机械功能/故障指示
2 型电涌保护器类同 EN / IEC 61643-41
由开关/火花间隙组合而成
专门设计用于最高电压为 1250 V 的直流充电系统
最大持续工作电压 (+ --> -)：1250 V DC
标称放电电流 (8/20 µs)：10 kA
无电势远程信号触点用作转换接触件
已按照 EN60068 标准通过了振动与冲击测试
符合 IEC 61851-23 标准

制造商： DEHN
型号: DG M DC ACI 1250 FM
货号: 972150
其他类似产品

Certificates



ACI-Technology

A further development of CI technology, ACI technology consists of a switch/spark gap combination connected in series with a heavyduty varistor. This ensures the simple design and safe operation of the surge protective device. Other features are safe dimensioning, TOV withstand, a connection cross-section of only 6 mm² Cu and zero leakage current. Surge arresters with ACI technology offer maximum safety and system availability.

Technical data

电涌保护器类同 EN 61643-41 / ... IEC 61643-41 2 型/ II 级
直流最大持续工作电压[DC+ --> DC-] (UC ) 1250 V
直流最大持续工作电压 [(DC+/DC-) --> PE] (UC ) 625 V
标称放电电流 (8/20 µs) (In ) 10 kA
最大标称放电电流 (8/20 µs) (I最大 ) 20 kA
电压保护水平 [DC+ --> DC-] (Up ) < 5 kV
电压保护水平 [(DC+/DC-) --> PE] (Up ) < 2.5 kV
最大短路耐受能力 (ISCCR ) 5 kA
遥信触点类型 浮动切换触点

Product 972150 was added to Notepad.

Go to Notepad

Product 972150 was added to the cart.

Go to Web-Shop

DEHNguard ME DC ... FM

直流应用的模块化复合型电涌保护器；带遥信端子。

1 Product

Part No. 972147 DG ME DC Y 1000 FM

GTIN 4013364519817, Customs tariff No. (EU): 853630, Gross weight: 530.49 g, PU: 1.00 件

Images

Additional information

1+2 复合型电涌保护器 DEHNguard ME DC Y 1000 FM
3 极、模块化、可插拔复合型电涌保护器
适合直流电用途，宽度为 4 个分区单元
机械功能/故障指示
符合 EN 61643-11 标准的 1+2 型电涌保护器，采样 Y 型电路设计
采用无泄漏电流变阻器气体电涌保护器技术
专用于直流电路，适合电压高达 1000 V 的
直流开关装置 DCD
最大持续工作电压：1000 V dc
雷电冲击电流 5kA (10/350µs)
标称放电电流：12.5 kA (8/20µs)
无电势远程信号触点用作转换接触件
已按照 EN60068 标准通过了振动与冲击测试

制造商： DEHN
型号: DG ME DC Y 1000 FM
货号: 972147
其他类似产品

Certificates



Direct Current-Disconnection

When using surge arresters in d.c. applications, disconnection must be reliably ensured even if there are no zero crossings. The specifically developed DC Disconnection (DCD) technology acts as a wedge similar to a blocking valve and interrupts the direct current. Consequently, the devices of the DEHNguard SE DC series are capable of safely interrupting direct currents, thus preventing fire damage caused by d.c. switching arcs.

Technical data

SPD类同 EN 61643-11 / IEC 61643-11 1级+2级 / I级+II级
直流最大持续工作电压 (UC ) 1000 V
雷电冲击电流 (10/350 μs) (Iimp ) 5 kA
标称放电电流 (8/20 µs) (In ) 12.5 kA
电压保护水平 [DC+ --> DC-] (Up ) < 3.75 kV
电压保护水平 [(DC+/DC-) --> PE] (Up ) < 2.5 kV
最大短路耐受能力 (ISCCR ) 500 A / 170 ms
遥信触点类型 浮动切换触点

Product 972147 was added to Notepad.

Go to Notepad

Product 972147 was added to the cart.

Go to Web-Shop

DEHNguard SE DC ...

直流应用的单极模块化电涌保护器。

4 Products

Part No. 972110 DG SE DC 60

GTIN 4013364158504, Customs tariff No. (EU): 853630, Gross weight: 160.00 g, PU: 1.00 件

Images

Additional information

DEHNguard SE DC 60 电涌保护器
单极模块可插拔电涌保护器
直流应用，1.5模宽度
故障指示
依据EN61643-11，2级SPD
高性能压敏电阻
DCD直流切断技术，特别适用于直流电路
直流最大持续工作电压：60V
电压保护水平：≤ 0.5kV
标称放电电流 (8/20)：12.5kA
最大直流后备熔丝时短路耐受能力：2000A
依据IEC 62305-4与其它DEHN红线产品能量协调使用

制造商： DEHN
型号: DG SE DC 60
货号: 972110
其他类似产品

Certificates



Direct Current-Disconnection

When using surge arresters in d.c. applications, disconnection must be reliably ensured even if there are no zero crossings. The specifically developed DC Disconnection (DCD) technology acts as a wedge similar to a blocking valve and interrupts the direct current. Consequently, the devices of the DEHNguard SE DC series are capable of safely interrupting direct currents, thus preventing fire damage caused by d.c. switching arcs.

Technical data

SPD依据 EN 61643-11 / IEC 61643-11 2级 / II级
直流最大持续工作电压 (UC ) 60 V
标称放电电流 (8/20 µs) (In ) 12.5 kA
电压保护水平 (UP ) ≤ 0.5 kV
无直流后备熔丝时短路耐受能力 (ISCCR ) 300 A
最大直流后备熔丝时短路耐受能力 (ISCCR ) 25 kA
最大后备熔丝 35 A gG

Product 972110 was added to Notepad.

Go to Notepad

Product 972110 was added to the cart.

Go to Web-Shop

Part No. 972120 DG SE DC 242

GTIN 4013364158528, Customs tariff No. (EU): 853630, Gross weight: 170.00 g, PU: 1.00 件

Images

Additional information

DEHNguard SE DC 242 电涌保护器
单极模块可插拔电涌保护器
直流应用，1.5模宽度
故障指示
依据EN61643-11，2级SPD
高性能压敏电阻
DCD直流切断技术，特别适用于直流电路
直流最大持续工作电压：242V
电压保护水平：≤ 1.25kV
标称放电电流 (8/20)：12.5kA
最大直流后备熔丝时短路耐受能力：2000A
依据IEC 62305-4与其它DEHN红线产品能量协调使用

制造商： DEHN
型号: DG SE DC 242
货号: 972120
其他类似产品

Certificates



Direct Current-Disconnection

When using surge arresters in d.c. applications, disconnection must be reliably ensured even if there are no zero crossings. The specifically developed DC Disconnection (DCD) technology acts as a wedge similar to a blocking valve and interrupts the direct current. Consequently, the devices of the DEHNguard SE DC series are capable of safely interrupting direct currents, thus preventing fire damage caused by d.c. switching arcs.

Technical data

SPD依据 EN 61643-11 / IEC 61643-11 2级 / II级
直流最大持续工作电压 (UC ) 242 V
标称放电电流 (8/20 µs) (In ) 12.5 kA
电压保护水平 (UP ) ≤ 1.25 kV
无直流后备熔丝时短路耐受能力 (ISCCR ) 300 A
最大直流后备熔丝时短路耐受能力 (ISCCR ) 25 kA
最大后备熔丝 35 A gG

Product 972120 was added to Notepad.

Go to Notepad

Product 972120 was added to the cart.

Go to Web-Shop

Part No. 972130 DG SE DC 550

GTIN 4013364158627, Customs tariff No. (EU): 853630, Gross weight: 184.00 g, PU: 1.00 件

Images

Additional information

DEHNguard SE DC 550 电涌保护器
单极模块可插拔电涌保护器
直流应用，1.5模宽度
故障指示
依据EN61643-11，2级SPD
高性能压敏电阻
DCD直流切断技术，特别适用于直流电路
直流最大持续工作电压：550V
电压保护水平：≤ 2.0kV
标称放电电流 (8/20)：12.5kA
最大直流后备熔丝时短路耐受能力：2000A
依据IEC 62305-4与其它DEHN红线产品能量协调使用

制造商： DEHN
型号: DG SE DC 550
货号: 972130
其他类似产品

Certificates



Direct Current-Disconnection

When using surge arresters in d.c. applications, disconnection must be reliably ensured even if there are no zero crossings. The specifically developed DC Disconnection (DCD) technology acts as a wedge similar to a blocking valve and interrupts the direct current. Consequently, the devices of the DEHNguard SE DC series are capable of safely interrupting direct currents, thus preventing fire damage caused by d.c. switching arcs.

Technical data

SPD依据 EN 61643-11 / IEC 61643-11 2级 / II级
直流最大持续工作电压 (UC ) 550 V
标称放电电流 (8/20 µs) (In ) 12.5 kA
电压保护水平 (UP ) ≤ 2.0 kV
无直流后备熔丝时短路耐受能力 (ISCCR ) 200 A
最大直流后备熔丝时短路耐受能力 (ISCCR ) 25 kA
最大后备熔丝 35 A gG

Product 972130 was added to Notepad.

Go to Notepad

Product 972130 was added to the cart.

Go to Web-Shop

Part No. 972140 DG SE DC 900

GTIN 4013364158641, Customs tariff No. (EU): 853630, Gross weight: 190.00 g, PU: 1.00 件

Images

Additional information

DEHNguard SE DC 900 电涌保护器
单极模块可插拔电涌保护器
直流应用，1.5模宽度
故障指示
依据EN61643-11，2级SPD
高性能压敏电阻
DCD直流切断技术，特别适用于直流电路
直流最大持续工作电压：900V
电压保护水平：≤ 3.0kV
标称放电电流 (8/20)：12.5kA
最大直流后备熔丝时短路耐受能力：2000A
依据IEC 62305-4与其它DEHN红线产品能量协调使用

制造商： DEHN
型号: DG SE DC 900
货号: 972140
其他类似产品

Certificates



Direct Current-Disconnection

When using surge arresters in d.c. applications, disconnection must be reliably ensured even if there are no zero crossings. The specifically developed DC Disconnection (DCD) technology acts as a wedge similar to a blocking valve and interrupts the direct current. Consequently, the devices of the DEHNguard SE DC series are capable of safely interrupting direct currents, thus preventing fire damage caused by d.c. switching arcs.

Technical data

SPD依据 EN 61643-11 / IEC 61643-11 2级 / II级
直流最大持续工作电压 (UC ) 900 V
标称放电电流 (8/20 µs) (In ) 12.5 kA
电压保护水平 (UP ) ≤ 3.0 kV
无直流后备熔丝时短路耐受能力 (ISCCR ) 100 A
最大直流后备熔丝时短路耐受能力 (ISCCR ) 25 kA
最大后备熔丝 80 A gPV

Product 972140 was added to Notepad.

Go to Notepad

Product 972140 was added to the cart.

Go to Web-Shop

DEHNguard SE DC ... FM

直流应用的单极模块化电涌保护器，带遥信端子。

4 Products

Part No. 972115 DG SE DC 60 FM

GTIN 4013364158511, Customs tariff No. (EU): 853630, Gross weight: 164.00 g, PU: 1.00 件

Images

Additional information

DEHNguard SE DC 60 FM 电涌保护器
单极模块可插拔电涌保护器
直流应用，1.5模宽度
故障指示
依据EN61643-11，2级SPD
带遥信端子
高性能压敏电阻
DCD直流切断技术，特别适用于直流电路
直流最大持续工作电压：60V
电压保护水平：≤ 0.5kV
标称放电电流 (8/20)：12.5kA
最大直流后备熔丝时短路耐受能力：2000A
依据IEC 62305-4与其它DEHN红线产品能量协调使用

制造商： DEHN
型号: DG SE DC 60 FM
货号: 972115
其他类似产品

Certificates



Direct Current-Disconnection

When using surge arresters in d.c. applications, disconnection must be reliably ensured even if there are no zero crossings. The specifically developed DC Disconnection (DCD) technology acts as a wedge similar to a blocking valve and interrupts the direct current. Consequently, the devices of the DEHNguard SE DC series are capable of safely interrupting direct currents, thus preventing fire damage caused by d.c. switching arcs.

Technical data

SPD依据 EN 61643-11 / IEC 61643-11 2级 / II级
直流最大持续工作电压 (UC ) 60 V
标称放电电流 (8/20 µs) (In ) 12.5 kA
电压保护水平 (UP ) ≤ 0.5 kV
无直流后备熔丝时短路耐受能力 (ISCCR ) 300 A
最大直流后备熔丝时短路耐受能力 (ISCCR ) 25 kA
最大后备熔丝 35 A gG
遥信触点类型 浮动切换触点

Product 972115 was added to Notepad.

Go to Notepad

Product 972115 was added to the cart.

Go to Web-Shop

Part No. 972125 DG SE DC 242 FM

GTIN 4013364158610, Customs tariff No. (EU): 853630, Gross weight: 174.00 g, PU: 1.00 件

Images

Additional information

DEHNguard SE DC 242 FM 电涌保护器
单极模块可插拔电涌保护器
直流应用，1.5模宽度
故障指示
依据EN61643-11，2级SPD
带遥信端子
高性能压敏电阻
DCD直流切断技术，特别适用于直流电路
直流最大持续工作电压：242V
电压保护水平：≤ 1.25kV
标称放电电流 (8/20)：12.5kA
最大直流后备熔丝时短路耐受能力：2000A
依据IEC 62305-4与其它DEHN红线产品能量协调使用

制造商： DEHN
型号: DG SE DC 242 FM
货号: 972125
其他类似产品

Certificates



Direct Current-Disconnection

When using surge arresters in d.c. applications, disconnection must be reliably ensured even if there are no zero crossings. The specifically developed DC Disconnection (DCD) technology acts as a wedge similar to a blocking valve and interrupts the direct current. Consequently, the devices of the DEHNguard SE DC series are capable of safely interrupting direct currents, thus preventing fire damage caused by d.c. switching arcs.

Technical data

SPD依据 EN 61643-11 / IEC 61643-11 2级 / II级
直流最大持续工作电压 (UC ) 242 V
标称放电电流 (8/20 µs) (In ) 12.5 kA
电压保护水平 (UP ) ≤ 1.25 kV
无直流后备熔丝时短路耐受能力 (ISCCR ) 300 A
最大直流后备熔丝时短路耐受能力 (ISCCR ) 25 kA
最大后备熔丝 35 A gG
遥信触点类型 浮动切换触点

Product 972125 was added to Notepad.

Go to Notepad

Product 972125 was added to the cart.

Go to Web-Shop

Part No. 972135 DG SE DC 550 FM

GTIN 4013364158634, Customs tariff No. (EU): 853630, Gross weight: 189.00 g, PU: 1.00 件

Images

Additional information

DEHNguard SE DC 550 FM 电涌保护器
单极模块可插拔电涌保护器
直流应用，1.5模宽度
故障指示
依据EN61643-11，2级SPD
带遥信端子
高性能压敏电阻
DCD直流切断技术，特别适用于直流电路
直流最大持续工作电压：550V
电压保护水平：≤ 2.0kV
标称放电电流 (8/20)：12.5kA
最大直流后备熔丝时短路耐受能力：2000A
依据IEC 62305-4与其它DEHN红线产品能量协调使用

制造商： DEHN
型号: DG SE DC 550 FM
货号: 972135
其他类似产品

Certificates



Direct Current-Disconnection

When using surge arresters in d.c. applications, disconnection must be reliably ensured even if there are no zero crossings. The specifically developed DC Disconnection (DCD) technology acts as a wedge similar to a blocking valve and interrupts the direct current. Consequently, the devices of the DEHNguard SE DC series are capable of safely interrupting direct currents, thus preventing fire damage caused by d.c. switching arcs.

Technical data

SPD依据 EN 61643-11 / IEC 61643-11 2级 / II级
直流最大持续工作电压 (UC ) 550 V
标称放电电流 (8/20 µs) (In ) 12.5 kA
电压保护水平 (UP ) ≤ 2.0 kV
无直流后备熔丝时短路耐受能力 (ISCCR ) 200 A
最大直流后备熔丝时短路耐受能力 (ISCCR ) 25 kA
最大后备熔丝 35 A gG
遥信触点类型 浮动切换触点

Product 972135 was added to Notepad.

Go to Notepad

Product 972135 was added to the cart.

Go to Web-Shop

Part No. 972145 DG SE DC 900 FM

GTIN 4013364158658, Customs tariff No. (EU): 853630, Gross weight: 194.00 g, PU: 1.00 件

Images

Additional information

DEHNguard SE DC 900 FM 电涌保护器
单极模块可插拔电涌保护器
直流应用，1.5模宽度
故障指示
依据EN61643-11，2级SPD
带遥信端子
高性能压敏电阻
DCD直流切断技术，特别适用于直流电路
直流最大持续工作电压：900V
电压保护水平：≤ 3.0kV
标称放电电流 (8/20)：12.5kA
最大直流后备熔丝时短路耐受能力：2000A
依据IEC 62305-4与其它DEHN红线产品能量协调使用

制造商： DEHN
型号: DG SE DC 900 FM
货号: 972145
其他类似产品

Certificates



Direct Current-Disconnection

When using surge arresters in d.c. applications, disconnection must be reliably ensured even if there are no zero crossings. The specifically developed DC Disconnection (DCD) technology acts as a wedge similar to a blocking valve and interrupts the direct current. Consequently, the devices of the DEHNguard SE DC series are capable of safely interrupting direct currents, thus preventing fire damage caused by d.c. switching arcs.

Technical data

SPD依据 EN 61643-11 / IEC 61643-11 2级 / II级
直流最大持续工作电压 (UC ) 900 V
标称放电电流 (8/20 µs) (In ) 12.5 kA
电压保护水平 (UP ) ≤ 3.0 kV
无直流后备熔丝时短路耐受能力 (ISCCR ) 100 A
最大直流后备熔丝时短路耐受能力 (ISCCR ) 25 kA
最大后备熔丝 80 A gPV
遥信触点类型 浮动切换触点

Product 972145 was added to Notepad.

Go to Notepad

Product 972145 was added to the cart.

Go to Web-Shop
