DEHNguard modular E (Y)PV SCI 1500

  • 完整的预接线单元，由底座和插入式保护模块两部分组成，用于最大1500V直流光伏系统
  • 保护模块内集成脱离和短路装置，具有安全的电气隔离，防止直流拉弧造成的火灾隐患（专利SCI设计）
  • 内置直流熔丝可保证安全的更换保护模块，且无拉弧现象产生
  • 产品的全新设计使其可安全运用于最大1500V直流光伏系统
  • 依据EN 50539-11 测试
  • 适用于所有依据IEC 60364-7-712的光伏系统

Details

三步直流脱扣装置（专利SCI设计）
lorem ipsum

DEHNguard ME YPV SCI 1500 (FM)

多极模块化电涌保护器，用于光伏系统保护，带三步直流脱扣装置。

2 Products

Part No. 952520 DG ME YPV SCI 1500

GTIN 4013364149069, Customs tariff No. (EU): 853540, Gross weight: 535.70 g, PU: 1.00 件

Images

Additional information

DEHNguard ME YPV SCI 1500 电涌保护器
多极模块可插拔电涌保护器，用于最高直流1500V的光伏系统
带三步直流脱扣装置，4.5模宽度
故障指示
依据EN 50539-11，2级SPD
可用于IEC 60364-7-712
保护模块内集成脱离和短路装置
最大光伏电压： ≤ 1500 V
总放电电流：25 kA
电压保护水平：≤ 6 kV
额定短路电流 Iscpv：10 kA

制造商： DEHN
型号: DG ME YPV SCI 1500
货号: 952520
其他类似产品

Certificates



SCI-Technology

The patented SCI technology with active arc extinction allows to actively, quickly and safely extinguish a possible switching arc in case of overload. The PV fuse integrated in the short-circuit path trips immediately after the arc has been extinguished, thus ensuring safe electrical isolation (interruption). Consequently, all PV arresters from DEHN combine surge protection, fire protection and personal protection in a single device

Technical data

电涌保护器符合 EN 61643-31 / ... IEC 61643-31 标准 2 型/ II 级
最大光伏电压 (UCPV ) 1500 V
额定短路电流 (ISCPV ) 10 kA
总放电电流 (8/20 µs) (Itotal ) 25 kA
标称放电电流 (8/20 µs) [(DC+/DC-) --> PE] (In ) 12.5 kA
电压保护水平 (UP ) ≤ 6 kV
认证 KEMA, UL

Product 952520 was added to Notepad.

Go to Notepad

Product 952520 was added to the cart.

Go to Web-Shop

Part No. 952525 DG ME YPV SCI1500 FM

GTIN 4013364149076, Customs tariff No. (EU): 853540, Gross weight: 556.00 g, PU: 1.00 件

Images

Additional information

DEHNguard ME YPV SCI 1500 FM 电涌保护器
多极模块可插拔电涌保护器，用于最高直流1500V的光伏系统
带三步直流脱扣装置，4.5模宽度
故障指示
带遥信端子
依据EN 50539-11，2级SPD
可用于IEC 60364-7-712
保护模块内集成脱离和短路装置
最大光伏电压： ≤ 1500 V
总放电电流：25 kA
电压保护水平：≤ 6 kV
额定短路电流 Iscpv：10 kA

制造商： DEHN
型号: DG ME YPV SCI1500 FM
货号: 952525
其他类似产品

Certificates



SCI-Technology

The patented SCI technology with active arc extinction allows to actively, quickly and safely extinguish a possible switching arc in case of overload. The PV fuse integrated in the short-circuit path trips immediately after the arc has been extinguished, thus ensuring safe electrical isolation (interruption). Consequently, all PV arresters from DEHN combine surge protection, fire protection and personal protection in a single device

Technical data

电涌保护器符合 EN 61643-31 / ... IEC 61643-31 标准 2 型/ II 级
最大光伏电压 (UCPV ) 1500 V
额定短路电流 (ISCPV ) 10 kA
总放电电流 (8/20 µs) (Itotal ) 25 kA
标称放电电流 (8/20 µs) [(DC+/DC-) --> PE] (In ) 12.5 kA
电压保护水平 (UP ) ≤ 6 kV
认证 KEMA, UL
遥信触点类型 浮动切换触点
