紧凑型 DEHNguard YPV SCI ...

  • 适合光伏设备的完整的预装单元
  • 组合脱离和短路装置，具有安全电气隔离（专利 SCI 设计）
  • DEHNguard YPV SCI … 经过验证的防故障 Y 型电路，可防止光伏直流回路绝缘故障对电涌保护器造成的损坏
  • 依据 EN 61643-31 测试
  • 依据 IEC 60364-7-712，用于光伏系统

Details

三步直流脱扣装置（专利SCI 设计）
lorem ipsum

紧凑型 DEHNguard YPV SCI ...

多极电涌保护器，用于光伏系统保护，带三步直流脱扣装置。

2 Products

Part No. 950531 DG YPV SCI 600

GTIN 4013364152953, Customs tariff No. (EU): 853630, Gross weight: 296.00 g, PU: 1.00 件

Predecessor

Images

Additional information

电涌保护器 DEHNguard kompakt YPV SCI 600
多级光伏系统电涌保护器，最高 600 VDC
，配备 3 级直流开关装置，宽度 3 个分区单元
故障指示
符合 EN 61643-31 的 2 型
依据 IEC 60364-7-712 使用
安全电压
最大光伏电压： <= 600 V dc
总放电电流：40 kA
电压保护水平：<= 2.5 kV
短路耐受能力 Iscpv：1000 A

制造商： DEHN
型号: DG YPV SCI 600
货号: 950531
其他类似产品

Certificates



SCI-Technology

The patented SCI technology with active arc extinction allows to actively, quickly and safely extinguish a possible switching arc in case of overload. The PV fuse integrated in the short-circuit path trips immediately after the arc has been extinguished, thus ensuring safe electrical isolation (interruption). Consequently, all PV arresters from DEHN combine surge protection, fire protection and personal protection in a single device

Technical data

电涌保护器符合 EN 61643-31 / ... IEC 61643-31 标准 2 型/ II 级
最大光伏电压 (UCPV ) 600 V
额定短路电流 (ISCPV ) 1000 A
标称放电电流 (8/20 µs) [(DC+/DC-) --> PE] (In ) 12.5 kA
最大放电电流 (8/20 µs) [(DC+/DC-) --> PE] (Imax ) 25 kA
电压保护水平 (UP ) ≤ 2.5 kV
认证 KEMA, UL

Product 950531 was added to Notepad.

Go to Notepad

Product 950531 was added to the cart.

Go to Web-Shop

Part No. 950530 DG YPV SCI 1000

GTIN 4013364152960, Customs tariff No. (EU): 853630, Gross weight: 321.00 g, PU: 1.00 件

Images

Additional information

电涌保护器 DEHNguard kompakt YPV SCI 1000
多级光伏系统电涌保护器，最高 1000 V DC，
配备 3 级 DC 开关装置，宽度 3 个分区单元
故障指示
符合 EN 61643-31 的 2 型
依据 IEC 60364-7-71 使用
安全电压
最大光伏电压：<= 1000 V dc
总放电电流：40 kA
电压保护水平：<= 4 kV
短路耐受能力 Iscpv：1000 A

制造商： DEHN
型号: DG YPV SCI 1000
货号: 950530
其他类似产品

Certificates



SCI-Technology

The patented SCI technology with active arc extinction allows to actively, quickly and safely extinguish a possible switching arc in case of overload. The PV fuse integrated in the short-circuit path trips immediately after the arc has been extinguished, thus ensuring safe electrical isolation (interruption). Consequently, all PV arresters from DEHN combine surge protection, fire protection and personal protection in a single device

Technical data

电涌保护器符合 EN 61643-31 / ... IEC 61643-31 标准 2 型/ II 级
最大光伏电压 (UCPV ) 1000 V
额定短路电流 (ISCPV ) 1000 A
标称放电电流 (8/20 µs) [(DC+/DC-) --> PE] (In ) 12.5 kA
最大放电电流 (8/20 µs) [(DC+/DC-) --> PE] (Imax ) 25 kA
电压保护水平 (UP ) ≤ 4 kV
认证 KEMA, UL

Product 950530 was added to Notepad.

Go to Notepad

Product 950530 was added to the cart.

Go to Web-Shop

紧凑型 DEHNguard YPV SCI ... FM

多极电涌保护器，用于光伏系统保护，带三步直流脱扣装置及遥信端子（浮动切换触点）。

2 Products

Part No. 950536 DG YPV SCI 600 FM

GTIN 4013364154995, Customs tariff No. (EU): 853630, Gross weight: 306.00 g, PU: 1.00 件

Predecessor

Images

Additional information

电涌保护器 DEHNguard kompakt YPV SCI 600 FM
多级光伏系统电涌保护器，最高 600 VDC
，配备 3 级直流开关装置，宽度 3 个分区单元
故障显示，带远程信号触点
符合 EN 61643-31 的 2 型
依据 IEC 60364-7-712 使用
安全电压
最大光伏电压：<= 600 V dc
总放电电流：40 kA
电压保护水平：<= 2.5 kV
短路耐受能力 Iscpv：1000 A

制造商： DEHN
型号: DG YPV SCI 600 FM
货号: 950536
其他类似产品

Certificates



SCI-Technology

The patented SCI technology with active arc extinction allows to actively, quickly and safely extinguish a possible switching arc in case of overload. The PV fuse integrated in the short-circuit path trips immediately after the arc has been extinguished, thus ensuring safe electrical isolation (interruption). Consequently, all PV arresters from DEHN combine surge protection, fire protection and personal protection in a single device

Technical data

电涌保护器符合 EN 61643-31 / ... IEC 61643-31 标准 2 型/ II 级
最大光伏电压 (UCPV ) 600 V
额定短路电流 (ISCPV ) 1000 A
标称放电电流 (8/20 µs) [(DC+/DC-) --> PE] (In ) 12.5 kA
最大放电电流 (8/20 µs) [(DC+/DC-) --> PE] (Imax ) 25 kA
电压保护水平 (UP ) ≤ 2.5 kV
认证 KEMA, UL
遥信触点类型 浮动切换触点

Product 950536 was added to Notepad.

Go to Notepad

Product 950536 was added to the cart.

Go to Web-Shop

Part No. 950535 DG YPV SCI 1000 FM

GTIN 4013364154988, Customs tariff No. (EU): 853630, Gross weight: 331.00 g, PU: 1.00 件

Images

Additional information

电涌保护器 DEHNguard kompakt YPV SCI 1000 FM
多级光伏系统电涌保护器，最高 1000 V DC，
配备 3 级 DC 开关装置，宽度 3 个分区单元
故障显示，带远程信号触点
符合 EN 61643-31 的 2 型
依据 IEC 60364-7-712 使用
安全电压
最大光伏电压：<= 1000 V dc
总放电电流：40 kA
电压保护水平：<= 4 kV
短路耐受能力 Iscpv：1000 A

制造商： DEHN
型号: DG YPV SCI 1000 FM
货号: 950535
其他类似产品

Certificates



SCI-Technology

The patented SCI technology with active arc extinction allows to actively, quickly and safely extinguish a possible switching arc in case of overload. The PV fuse integrated in the short-circuit path trips immediately after the arc has been extinguished, thus ensuring safe electrical isolation (interruption). Consequently, all PV arresters from DEHN combine surge protection, fire protection and personal protection in a single device

Technical data

电涌保护器符合 EN 61643-31 / ... IEC 61643-31 标准 2 型/ II 级
最大光伏电压 (UCPV ) 1000 V
额定短路电流 (ISCPV ) 1000 A
标称放电电流 (8/20 µs) [(DC+/DC-) --> PE] (In ) 12.5 kA
最大放电电流 (8/20 µs) [(DC+/DC-) --> PE] (Imax ) 25 kA
电压保护水平 (UP ) ≤ 4 kV
认证 KEMA, UL
遥信触点类型 浮动切换触点

Product 950535 was added to Notepad.

Go to Notepad

Product 950535 was added to the cart.

Go to Web-Shop
