DEHNguard modular (Y)PV SCI ...

  • 预装模块化电涌保护器，用于光伏系统保护，由底座和插入式保护模块两部分组成
  • 保护模块内的组合式脱离和短路装置，具有安全电气隔离（获得了专利的 SCI 设计）
  • DEHNguard M YPV SCI … (FM) 经过验证的防故障 Y 型电路，可防止光伏直流回路绝缘故障对电涌保护器造成的损坏
  • 依据 EN 61643-31 测试
  • 适用于所有依据 IEC 60364-7-712 的光伏系统

Details

lorem ipsum
三步直流脱扣装置 （专利SCI设计）
lorem ipsum

DEHNguard M YPV SCI ...

多极模块化电涌保护器，用于光伏系统保护，带三步直流脱扣装置。

3 Products

Part No. 952513 DG M YPV SCI 150

GTIN 4013364136663, Customs tariff No. (EU): 853630, Gross weight: 289.70 g, PU: 1.00 件

Images

Additional information

DEHNguard M YPV SCI 150 电涌保护器
多极模块可插拔电涌保护器，用于最高直流150V的光伏系统
带三步直流脱扣装置，3模宽度
故障指示
依据EN 50539-11，2级SPD
可用于IEC 60364-7-712
保护模块内集成脱离和短路装置
最大光伏电压： ≤ 150 V
总放电电流：40 kA
电压保护水平：≤ 0.8 kV
额定短路电流 Iscpv：10 kA

制造商： DEHN
型号: DG M YPV SCI 150
货号: 952513
其他类似产品

Certificates



SCI-Technology

The patented SCI technology with active arc extinction allows to actively, quickly and safely extinguish a possible switching arc in case of overload. The PV fuse integrated in the short-circuit path trips immediately after the arc has been extinguished, thus ensuring safe electrical isolation (interruption). Consequently, all PV arresters from DEHN combine surge protection, fire protection and personal protection in a single device

Technical data

电涌保护器符合 EN 61643-31 / ... IEC 61643-31 标准 2 型
最大光伏电压 (UCPV ) 150 V
额定短路电流 (ISCPV ) 10 kA
标称放电电流 (8/20 μs) [(DC+/DC-) --> PE] (In ) 10 kA
最大放电电流 (8/20 μs) [(DC+/DC-) --> PE] (Imax ) 20 kA
电压保护水平 (UP ) ≤ 0.8 kV
认证 KEMA, UL, CSA

Product 952513 was added to Notepad.

Go to Notepad

Product 952513 was added to the cart.

Go to Web-Shop

Part No. 952510 DG M YPV SCI 1000

GTIN 4013364126428, Customs tariff No. (EU): 853630, Gross weight: 361.40 g, PU: 1.00 件

Predecessor

Images

Additional information

DEHNguard M YPV SCI 1000 电涌保护器
多极模块可插拔电涌保护器，用于最高直流 1000 V 的光伏系统
带 3 级直流开关装置，宽度 3 个分区单元
故障指示
符合 EN 61643-31 的 2 型
依据 IEC 60364-7-712 使用
保护模块内的安全电气隔离
最大光伏电压：<= 1000 V dc
总放电电流：40 kA
电压保护水平：<= 4 kV
短路耐受能力 Iscpv：10 kA

制造商： DEHN
型号: DG M YPV SCI 1000
货号: 952510
其他类似产品

Certificates



SCI-Technology

The patented SCI technology with active arc extinction allows to actively, quickly and safely extinguish a possible switching arc in case of overload. The PV fuse integrated in the short-circuit path trips immediately after the arc has been extinguished, thus ensuring safe electrical isolation (interruption). Consequently, all PV arresters from DEHN combine surge protection, fire protection and personal protection in a single device

Technical data

电涌保护器符合 EN 61643-31 / ... IEC 61643-31 标准 2 型/ II 级
最大光伏电压 (UCPV ) 1000 V
额定短路电流 (ISCPV ) 10 kA
标称放电电流 (8/20 μs) [(DC+/DC-) --> PE] (In ) 12.5 kA
最大放电电流 (8/20 μs) [(DC+/DC-) --> PE] (Imax ) 25 kA
电压保护水平 (UP ) ≤ 4 kV
认证 KEMA, UL, CSA

Product 952510 was added to Notepad.

Go to Notepad

Product 952510 was added to the cart.

Go to Web-Shop

Part No. 952512 DG M YPV SCI 1200

GTIN 4013364127951, Customs tariff No. (EU): 853540, Gross weight: 356.50 g, PU: 1.00 件

Predecessor

Images

Additional information

电涌保护器 DEHNguard M YPV SCI 1200
多级、模块化、可拔插光伏系统电涌保护器，最高 1200 V DC
，配备 3 级直流开关装置，宽度 3 个分区单元
故障指示
符合 EN 61643-31 的 2 型
依据 IEC 60364-7-712 使用
保护模块内的安全电气隔离
最大光伏电压：<= 1200 V dc
总放电电流：30 kA
电压保护水平：<= 4.5 kV
短路耐受能力 Iscpv：10 kA

制造商： DEHN
型号: DG M YPV SCI 1200
货号: 952512
其他类似产品

Certificates



SCI-Technology

The patented SCI technology with active arc extinction allows to actively, quickly and safely extinguish a possible switching arc in case of overload. The PV fuse integrated in the short-circuit path trips immediately after the arc has been extinguished, thus ensuring safe electrical isolation (interruption). Consequently, all PV arresters from DEHN combine surge protection, fire protection and personal protection in a single device

Technical data

电涌保护器符合 EN 61643-31 / ... IEC 61643-31 标准 2 型/ II 级
最大光伏电压 (UCPV ) 1200 V
额定短路电流 (ISCPV ) 10 kA
标称放电电流 (8/20 μs) [(DC+/DC-) --> PE] (In ) 12.5 kA
最大放电电流 (8/20 μs) [(DC+/DC-) --> PE] (Imax ) 25 kA
电压保护水平 (UP ) ≤ 4.5 kV
认证 KEMA, CSA

Product 952512 was added to Notepad.

Go to Notepad

Product 952512 was added to the cart.

Go to Web-Shop

DEHNguard M YPV SCI ... FM

多极模块化电涌保护器，用于光伏系统保护，带三步直流脱扣装置及遥信端子（浮动切换触点）。

3 Products

Part No. 952518 DG M YPV SCI 150 FM

GTIN 4013364136670, Customs tariff No. (EU): 853630, Gross weight: 297.00 g, PU: 1.00 件

Images

Additional information

DEHNguard M YPV SCI 150 FM 电涌保护器
多极模块可插拔电涌保护器，用于最高直流150V的光伏系统
带三步直流脱扣装置，3模宽度
故障指示
带遥信端子
依据EN 50539-11，2级SPD
可用于IEC 60364-7-712
保护模块内集成脱离和短路装置
最大光伏电压： ≤ 150 V
总放电电流：40 kA
电压保护水平：≤ 0.8 kV
额定短路电流 Iscpv：10 kA

制造商： DEHN
型号: DG M YPV SCI 150 FM
货号: 952518
其他类似产品

Certificates



SCI-Technology

The patented SCI technology with active arc extinction allows to actively, quickly and safely extinguish a possible switching arc in case of overload. The PV fuse integrated in the short-circuit path trips immediately after the arc has been extinguished, thus ensuring safe electrical isolation (interruption). Consequently, all PV arresters from DEHN combine surge protection, fire protection and personal protection in a single device

Technical data

SPD依据 EN 50539-11 2级
最大光伏电压 (UCPV ) 150 V
额定短路电流 (ISCPV ) 10 kA
标称放电电流 (8/20 μs) [(DC+/DC-) --> PE] (In ) 10 kA
最大放电电流 (8/20 μs) [(DC+/DC-) --> PE] (Imax ) 20 kA
电压保护水平 (UP ) ≤ 0.8 kV
认证 KEMA, UL, CSA
遥信触点类型 浮动切换触点

Product 952518 was added to Notepad.

Go to Notepad

Product 952518 was added to the cart.

Go to Web-Shop

Part No. 952515 DG M YPV SCI 1000 FM

GTIN 4013364126435, Customs tariff No. (EU): 853630, Gross weight: 343.90 g, PU: 1.00 件

Predecessor

Images

Additional information

电涌保护器 DEHNguard M YPV SCI 1000 FM
多级、模块化、可拔插光伏系统电涌保护器，最高 1000 V DC
，配备 3 级直流开关装置，宽度 3 个分区单元
故障显示，带远程信号触点
符合 EN 61643-31 的 2 型
依据 IEC 60364-7-712 使用
保护模块内的安全电气隔离
最大光伏电压：<= 1000 V dc
总放电电流：40 kA
电压保护水平：<= 4 kV
短路耐受能力 Iscpv：10 kA

制造商： DEHN
型号: DG M YPV SCI 1000 FM
货号: 952515
其他类似产品

Certificates



SCI-Technology

The patented SCI technology with active arc extinction allows to actively, quickly and safely extinguish a possible switching arc in case of overload. The PV fuse integrated in the short-circuit path trips immediately after the arc has been extinguished, thus ensuring safe electrical isolation (interruption). Consequently, all PV arresters from DEHN combine surge protection, fire protection and personal protection in a single device

Technical data

电涌保护器符合 EN 61643-31 / ... IEC 61643-31 标准 2 型/ II 级
最大光伏电压 (UCPV ) 1000 V
额定短路电流 (ISCPV ) 10 kA
标称放电电流 (8/20 μs) [(DC+/DC-) --> PE] (In ) 12.5 kA
最大放电电流 (8/20 μs) [(DC+/DC-) --> PE] (Imax ) 25 kA
电压保护水平 (UP ) ≤ 4 kV
认证 KEMA, UL, CSA
遥信触点类型 浮动切换触点

Product 952515 was added to Notepad.

Go to Notepad

Product 952515 was added to the cart.

Go to Web-Shop

Part No. 952517 DG M YPV SCI 1200 FM

GTIN 4013364127968, Customs tariff No. (EU): 853540, Gross weight: 359.30 g, PU: 1.00 件

Predecessor

Images

Additional information

电涌保护器 DEHNguard M YPV SCI 1200 FM
多级、模块化、可拔插光伏系统电涌保护器，最高 1200 V DC
，配备 3 级直流开关装置，宽度 3 个分区单元
故障显示，带远程信号触点
符合 EN 61643-31 的 2 型
依据 IEC 60364-7-712 使用
保护模块内的安全电气隔离
最大光伏电压：<= 1200 V dc
总放电电流：30 kA
电压保护水平：<= 4.5 kV
短路耐受能力 Iscpv：10 kA

制造商： DEHN
型号: DG M YPV SCI 1200 FM
货号: 952517
其他类似产品

Certificates



SCI-Technology

The patented SCI technology with active arc extinction allows to actively, quickly and safely extinguish a possible switching arc in case of overload. The PV fuse integrated in the short-circuit path trips immediately after the arc has been extinguished, thus ensuring safe electrical isolation (interruption). Consequently, all PV arresters from DEHN combine surge protection, fire protection and personal protection in a single device

Technical data

电涌保护器符合 EN 61643-31 / ... IEC 61643-31 标准 2 型/ II 级
最大光伏电压 (UCPV ) 1200 V
额定短路电流 (ISCPV ) 10 kA
标称放电电流 (8/20 μs) [(DC+/DC-) --> PE] (In ) 12.5 kA
最大放电电流 (8/20 μs) [(DC+/DC-) --> PE] (Imax ) 25 kA
电压保护水平 (UP ) ≤ 4.5 kV
认证 KEMA, CSA
遥信触点类型 浮动切换触点

Product 952517 was added to Notepad.

Go to Notepad

Product 952517 was added to the cart.

Go to Web-Shop

DEHNguard M PV2 SCI ... (FM)

多极模块化电涌保护器，用于最高直流1000V的2路MPP输入光伏系统，带三步直流脱扣装置及遥信端子（浮动切换触点）。

2 Products

Part No. 952514 DG M PV2 SCI 1000

GTIN 4013364224964, Customs tariff No. (EU): 853630, Gross weight: 588.00 g, PU: 1.00 件

Images

Additional information

电涌保护器 DEHNguard M PV2 SCI 1000
多级、模块化、可拔插光伏系统电涌保护器，最高 1000 V DC
，配备 3 级直流开关装置，宽度 5 个分区单元
故障指示
符合 EN 61643-31 的 2 型
依据 IEC 60364-7-712 使用
用于保护 2 个 MPP 输入端
保护模块内的安全电气隔离
最大光伏电压：<= 1000 V dc
总放电电流：40 kA
电压保护水平：<= 4 kV
短路耐受能力 Iscpv：10 kA

制造商： DEHN
型号: DG M PV2 SCI 1000
货号: 952514
其他类似产品

Certificates



SCI-Technology

The patented SCI technology with active arc extinction allows to actively, quickly and safely extinguish a possible switching arc in case of overload. The PV fuse integrated in the short-circuit path trips immediately after the arc has been extinguished, thus ensuring safe electrical isolation (interruption). Consequently, all PV arresters from DEHN combine surge protection, fire protection and personal protection in a single device

Technical data

电涌保护器符合 EN 61643-31 / ... IEC 61643-31 标准 2 型/ II 级
最大光伏电压 (UCPV ) 1000 V
额定短路电流 (ISCPV ) 10 kA
标称放电电流 (8/20 μs) [(DC+/DC-) --> PE] (In ) 12.5 kA
最大放电电流 (8/20 μs) [(DC+/DC-) --> PE] (Imax ) 25 kA
电压保护水平 (UP ) ≤ 4 kV
认证 UL, KEMA

Product 952514 was added to Notepad.

Go to Notepad

Product 952514 was added to the cart.

Go to Web-Shop

Part No. 952519 DG M PV2 SCI 1000 FM

GTIN 4013364224971, Customs tariff No. (EU): 853630, Gross weight: 599.00 g, PU: 1.00 件

Images

Additional information

电涌保护器 DEHNguard M PV2 SCI 1000 FM
多极模块可插拔电涌保护器，用于最高直流 1000 V 的光伏系统
配备 3 级直流开关装置，宽度为 5 个分区单元
故障显示，带远程信号触点
符合 EN 61643-31 的 2 型
依据 IEC 60364-7-712 使用
用于保护 2 个 MPP 输入端
保护模块内的安全电气隔离
最大光伏电压：<= 1000 V dc
总放电电流：40 kA
电压保护水平：<= 4 kV
短路耐受能力 Iscpv：10 kA

制造商： DEHN
型号: DG M PV2 SCI 1000 FM
货号: 952519
其他类似产品

Certificates



SCI-Technology

The patented SCI technology with active arc extinction allows to actively, quickly and safely extinguish a possible switching arc in case of overload. The PV fuse integrated in the short-circuit path trips immediately after the arc has been extinguished, thus ensuring safe electrical isolation (interruption). Consequently, all PV arresters from DEHN combine surge protection, fire protection and personal protection in a single device

Technical data

电涌保护器符合 EN 61643-31 / ... IEC 61643-31 标准 2 型/ II 级
最大光伏电压 (UCPV ) 1000 V
额定短路电流 (ISCPV ) 10 kA
标称放电电流 (8/20 μs) [(DC+/DC-) --> PE] (In ) 12.5 kA
最大放电电流 (8/20 μs) [(DC+/DC-) --> PE] (Imax ) 25 kA
电压保护水平 (UP ) ≤ 4 kV
认证 UL, KEMA
遥信触点类型 浮动切换触点

Product 952519 was added to Notepad.

Go to Notepad

Product 952519 was added to the cart.

Go to Web-Shop

DEHNguard M SN1868

多极模块化电涌保护器，用于3路MPP输入光伏系统，带三步直流脱扣装置及遥信端子（浮动切换触点）。

1 Product

Part No. 999799 DG M PV2 SCI SN1868 FM

GTIN 4013364328723, Customs tariff No. (EU): 853630, Gross weight: 598.30 g, PU: 1.00 件

Images

Additional information

电涌保护器 DEHNguard M PV2 SCI SN1868 FM
多级、模块化、可拔插光伏系统电涌保护器，最高 1000 V DC
，配备 3 级直流开关装置
配备遥信端子，宽度 5 个分区单元
符合 EN 61643-31 的 2 型
依据 IEC 60364-7-712 使用
用于保护 3 个 MPP 输入端
保护模块内的安全电气隔离
最大光伏电压：<= 1000 V dc
总放电电流：40 kA
电压保护水平：<= 4 kV
短路耐受能力 Iscpv：10 kA
故障指示

制造商： DEHN
型号: DG M PV2 SCI SN1868 FM
货号: 999799
其他类似产品

Certificates



SCI-Technology

The patented SCI technology with active arc extinction allows to actively, quickly and safely extinguish a possible switching arc in case of overload. The PV fuse integrated in the short-circuit path trips immediately after the arc has been extinguished, thus ensuring safe electrical isolation (interruption). Consequently, all PV arresters from DEHN combine surge protection, fire protection and personal protection in a single device

Technical data

电涌保护器符合 EN 61643-31 / ... IEC 61643-31 标准 2 型/ II 级
最大光伏电压 (UCPV ) 1000 V
额定短路电流 (ISCPV ) 10 kA
标称放电电流 (8/20 μs) [(DC+/DC-) --> PE] (In ) 12.5 kA
最大放电电流 (8/20 μs) [(DC+/DC-) --> PE] (Imax ) 25 kA
电压保护水平 (UP ) ≤ 4 kV
认证 UL, KEMA
遥信触点类型 浮动切换触点
