DEHNgap

  • 放电能力 100 kA (10/350 μs)
  • 总电流保护器尤其适用于，依据IEC 60634-5-53的TT系统中，“3+1”“1+1”电路的N线和PE线之间的保护。
  • 沿面放电火花间隙技术
  • 工作状态/故障以绿-红标记在监视窗口中指示

Details

lorem ipsum

DEHNgap M 255 (FM)

单极模块化能量协调型 N-PE 雷电流电涌保护器，UC = 255 V，带遥信端子（浮动切换触点）。

2 Products

Part No. 961101 DGP M 255

GTIN 4013364118676, Customs tariff No. (EU): 853630, Gross weight: 331.00 g, PU: 1.00 件

Predecessor

Images

Additional information

DEHNgap M 255 是一款能量协调型N-PE雷电流保护器
单极模块可插拔能量协调型N-PE雷电流保护器，2模宽度
依据EN 61643-11，1级SPD
沿面放电火花间隙
故障指示
雷电冲击电流(10/350)：100 kA
电压保护水平：≤ 1.5 kV
交流255V时续流遮断能力：100 Arms
TOV耐受：1200 V/200 ms
依据IEC 62305-4可与红线产品DEHNgap C S N-PE电涌保护器能量协调使用

制造商： DEHN
型号: DGP M 255
货号: 961101
其他类似产品

Certificates



Wave breaker function

In the case of spark-gap-based type 1 arresters, the entire current flows through the type 1 arrester during the discharge process. Like a wave breaker, the incoming energy is greatly broken down, which significantly relieves the downstream SPDs. All type 1 arresters in the Red/Line product range feature the WBF wave breaker function.

Technical data

SPD依据 EN 61643-11/...IEC 61643-11 1级 / I级
交流最大持续工作电压 (UC ) 255 V (50 / 60 Hz)
雷电冲击电流 (10/350 μs) (Iimp ) 100 kA
电压保护水平 (UP ) ≤ 1.5 kV
认证 VDE, KEMA, UL

Product 961101 was added to Notepad.

Go to Notepad

Product 961101 was added to the cart.

Go to Web-Shop

Part No. 961105 DGP M 255 FM

GTIN 4013364118683, Customs tariff No. (EU): 853630, Gross weight: 336.00 g, PU: 1.00 件

Predecessor

Images

Additional information

DEHNgap M 255 FM 是一款能量协调型 N-PE 雷电流电涌保护器
单极、模块化、可插拔的协调型 N-PE 雷电流电涌保护器，
2 模宽度
带遥信端子
符合 EN 61643-11 的 1 型电涌保护器
RADAX Flow 火花间隙技术
故障指示
标记指示故障
雷电冲击电流 (10/350 µs)：100 kA
电压保护水平：<= 1.5 kV
工频续流遮断能力：在 255 V ac 下 100 Arms
TOV 耐受能力：1200 V/200 ms
根据 DIN EN 62305-4 进行能源协调。
直接连接 Red/Line 系列的 DEHNgap C S N-PE 型电涌保护器

制造商： DEHN
型号: DGP M 255 FM
货号: 961105
其他类似产品

Certificates



Wave breaker function

In the case of spark-gap-based type 1 arresters, the entire current flows through the type 1 arrester during the discharge process. Like a wave breaker, the incoming energy is greatly broken down, which significantly relieves the downstream SPDs. All type 1 arresters in the Red/Line product range feature the WBF wave breaker function.

Technical data

SPD依据 EN 61643-11/...IEC 61643-11 1级 / I级
交流最大持续工作电压 (UC ) 255 V (50 / 60 Hz)
雷电冲击电流 (10/350 μs) (Iimp ) 100 kA
电压保护水平 (UP ) ≤ 1.5 kV
认证 VDE, KEMA, UL
遥信触点类型 浮动切换触点

Product 961105 was added to Notepad.

Go to Notepad

Product 961105 was added to the cart.

Go to Web-Shop

DEHNgap Maxi 1 255 (FM)

单极能量协调型N-PE雷电流保护器，FM版本带遥信端子。

2 Products

Part No. 961180 DGPM 1 255

GTIN 4013364157323, Customs tariff No. (EU): 853630, Gross weight: 460.00 g, PU: 1.00 件

Images

Additional information

N-PE 雷电流电涌保护器 DEHNgap Maxi 1 255
能量协调型 N-PE 雷电流电涌保护器，2 模宽度
符合 EN 61643-11 的 1 型电涌保护器
RADAX Flow 火花间隙技术
故障指示
雷电冲击电流 (10/350 µs)：100 kA
电压保护水平：<= 1.5 kV
工频续流遮断能力：在 255 V ac 下 100 Arms
TOV 耐受能力：1200 V/200 ms

制造商： DEHN
型号: DGPM 1 255
货号: 961180
其他类似产品

Certificates



Wave breaker function

In the case of spark-gap-based type 1 arresters, the entire current flows through the type 1 arrester during the discharge process. Like a wave breaker, the incoming energy is greatly broken down, which significantly relieves the downstream SPDs. All type 1 arresters in the Red/Line product range feature the WBF wave breaker function.

Technical data

SPD依据 EN 61643-11/...IEC 61643-11 1级+2级 / I级+II级
交流最大持续工作电压 (UC ) 255 V (50 / 60 Hz)
雷电冲击电流 (10/350 μs) (Iimp ) 100 kA
电压保护水平 (UP ) ≤ 1.5 kV
认证 KEMA

Product 961180 was added to Notepad.

Go to Notepad

Product 961180 was added to the cart.

Go to Web-Shop

Part No. 961185 DGPM 1 255 FM

GTIN 4013364157330, Customs tariff No. (EU): 853630, Gross weight: 460.00 g, PU: 1.00 件

Images

Additional information

N-PE 雷电流电涌保护器 DEHNgap Maxi 1 255 FM
能量协调型 N-PE 雷电流电涌保护器，2 模宽度
带遥信端子
符合 EN 61643-11 的 1 型电涌保护器
RADAX Flow 火花间隙技术
故障指示
雷电冲击电流 (10/350 µs)：100 kA
电压保护水平：<= 1.5 kV
工频续流遮断能力：在 255 V ac 下 100 Arms
TOV 耐受能力：1200 V/200 ms

制造商： DEHN
型号: DGPM 1 255 FM
货号: 961185
其他类似产品

Certificates



Wave breaker function

In the case of spark-gap-based type 1 arresters, the entire current flows through the type 1 arrester during the discharge process. Like a wave breaker, the incoming energy is greatly broken down, which significantly relieves the downstream SPDs. All type 1 arresters in the Red/Line product range feature the WBF wave breaker function.

Technical data

SPD依据 EN 61643-11/...IEC 61643-11 1级+2级 / I级+II级
交流最大持续工作电压 (UC ) 255 V (50 / 60 Hz)
雷电冲击电流 (10/350 μs) (Iimp ) 100 kA
电压保护水平 (UP ) ≤ 1.5 kV
认证 KEMA
遥信触点类型 浮动切换触点

Product 961185 was added to Notepad.

Go to Notepad

Product 961185 was added to the cart.

Go to Web-Shop

DEHNgap Maxi 440 (FM)

单极能量协调型N-PE雷电流保护器；FM版本带遥信端子。

2 Products

Part No. 961160 DGPM 440

GTIN 4013364116290, Customs tariff No. (EU): 853630, Gross weight: 415.00 g, PU: 1.00 件

Images

Additional information

N-PE 雷电流电涌保护器 DEHNgap Maxi 440
能量协调型 N-PE 雷电流电涌保护器，2 模宽度
符合 EN 61643-11 的 1 型电涌保护器
RADAX Flow 火花间隙技术
故障指示
雷电冲击电流 (10/350 µs)：100 kA
保护等级：<= 2.5 kV
工频续流遮断能力：在 440 V ac 下为 100 Arms
TOV 耐受能力：1200 V/200 ms

制造商： DEHN
型号: DGPM 440
货号: 961160
其他类似产品

Certificates



Wave breaker function

In the case of spark-gap-based type 1 arresters, the entire current flows through the type 1 arrester during the discharge process. Like a wave breaker, the incoming energy is greatly broken down, which significantly relieves the downstream SPDs. All type 1 arresters in the Red/Line product range feature the WBF wave breaker function.

Technical data

SPD依据 EN 61643-11/...IEC 61643-11 1级 / I级
交流最大持续工作电压 (UC ) 440 V (50 / 60 Hz)
雷电冲击电流 (10/350 μs) (Iimp ) 100 kA
电压保护水平 (UP ) ≤ 2.5 kV
认证 UL

Product 961160 was added to Notepad.

Go to Notepad

Product 961160 was added to the cart.

Go to Web-Shop

Part No. 961165 DGPM 440 FM

GTIN 4013364116306, Customs tariff No. (EU): 853630, Gross weight: 418.00 g, PU: 1.00 件

Images

Additional information

N-PE 雷电流电涌保护器 DEHNgap Maxi 440 FM
能量协调型 N-PE 雷电流电涌保护器，2 模宽度
带遥信端子
符合 EN 61643-11 的 1 型电涌保护器
RADAX Flow 火花间隙技术
故障指示
雷电冲击电流 (10/350 µs)：100 kA
保护等级：<= 2.5 kV
工频续流遮断能力：在 440 V ac 下为 100 Arms
TOV 耐受能力：1200 V/200 ms

制造商： DEHN
型号: DGPM 440 FM
货号: 961165
其他类似产品

Certificates



Wave breaker function

In the case of spark-gap-based type 1 arresters, the entire current flows through the type 1 arrester during the discharge process. Like a wave breaker, the incoming energy is greatly broken down, which significantly relieves the downstream SPDs. All type 1 arresters in the Red/Line product range feature the WBF wave breaker function.

Technical data

SPD依据 EN 61643-11/...IEC 61643-11 1级 / I级
交流最大持续工作电压 (UC ) 440 V (50 / 60 Hz)
雷电冲击电流 (10/350 μs) (Iimp ) 100 kA
电压保护水平 (UP ) ≤ 2.5 kV
认证 UL
遥信触点类型 浮动切换触点

Product 961165 was added to Notepad.

Go to Notepad

Product 961165 was added to the cart.

Go to Web-Shop

DEHNgap H M 255

单极模块化N-PE雷电流保护器。

1 Product

Part No. 961102 DGPH M 255

GTIN 4013364118690, Customs tariff No. (EU): 853630, Gross weight: 300.00 g, PU: 1.00 件

Predecessor

Images

Additional information

DEHNgap H M 255 是一款N-PE雷电流保护器
单极模块可插拔能量协调型N-PE雷电流保护器，2模宽度
依据EN 61643-11，1级SPD
沿面放电火花间隙
雷电冲击电流(10/350)：100 kA
电压保护水平：≤ 4 kV
交流255V时续流遮断能力：100 Arms
TOV耐受：1200 V/200 ms
依据IEC 62305-4可与红线产品DEHNgap C S N-PE电涌保护器能量协调使用

制造商： DEHN
型号: DGPH M 255
货号: 961102
其他类似产品

Certificates



Wave breaker function

In the case of spark-gap-based type 1 arresters, the entire current flows through the type 1 arrester during the discharge process. Like a wave breaker, the incoming energy is greatly broken down, which significantly relieves the downstream SPDs. All type 1 arresters in the Red/Line product range feature the WBF wave breaker function.

Technical data

SPD依据 EN 61643-11/...IEC 61643-11 1级 / I级
交流最大持续工作电压 (UC ) 255 V (50 / 60 Hz)
雷电冲击电流 (10/350 μs) (Iimp ) 100 kA
电压保护水平 (UP ) ≤ 4 kV
