DEHNbloc 模块化保护模块

  • 具有功能强大的“沿面放电火花间隙”，雷电流泄放能力高
  • RADAX Flow技术，具备续流抑制功能，满足系统高可靠性要求
  • 使用模块释放按钮，无需工具更换保护模块
  • 工作状态/故障以绿-红标记在监视窗口中指示
  • 更换可插拔保护模块时无需断电，也不需要移除垂直盖板

DB M 火花间隙保护模块

用于DEHNbloc M ...的火花间隙型保护模块。

3 Products

Part No. 961001 DB M MOD 150

GTIN 4013364118584, Customs tariff No. (EU): 853630, Gross weight: 184.90 g, PU: 1.00 件

Images

Additional information

火花间隙保护模块 DB M MOD 150
主电源火花间隙保护模块，
用于 Red/Line 产品系列中符合 EN 61643-11 标准的单极、协调、插拔式 1 型电涌保护器

RADAX Flow 续流抑制技术，
可最大程度的提高系统可靠性
最大持续工作电压：150 V AC
雷电冲击电流：35 kA
故障指示

制造商： DEHN
型号: DB M MOD 150
货号: 961001
其他类似产品

Certificates



Wave breaker function

In the case of spark-gap-based type 1 arresters, the entire current flows through the type 1 arrester during the discharge process. Like a wave breaker, the incoming energy is greatly broken down, which significantly relieves the downstream SPDs. All type 1 arresters in the Red/Line product range feature the WBF wave breaker function.

Technical data

交流最大持续工作电压 (UC ) 150
雷电冲击电流(10/350 μs) (Iimp ) 35 kA

Product 961001 was added to Notepad.

Go to Notepad

Product 961001 was added to the cart.

Go to Web-Shop

Part No. 961002 DB M MOD 255

GTIN 4013364118591, Customs tariff No. (EU): 853630, Gross weight: 207.00 g, PU: 1.00 件

Images

Additional information

火花间隙保护模块 DB M MOD 255
主电源火花间隙保护模块，
用于 Red/Line 产品系列中符合 EN 61643-11 标准的协调 1 型电涌保护器

RADAX Flow 续流抑制技术，
可最大程度的提高系统可靠性
最大持续工作电压：255 V ac
雷电冲击电流：50 kA
故障指示

制造商： DEHN
型号: DB M MOD 255
货号: 961002
其他类似产品

Certificates



Wave breaker function

In the case of spark-gap-based type 1 arresters, the entire current flows through the type 1 arrester during the discharge process. Like a wave breaker, the incoming energy is greatly broken down, which significantly relieves the downstream SPDs. All type 1 arresters in the Red/Line product range feature the WBF wave breaker function.

Technical data

交流最大持续工作电压 (UC ) 255
雷电冲击电流(10/350 μs) (Iimp ) 50 kA

Product 961002 was added to Notepad.

Go to Notepad

Product 961002 was added to the cart.

Go to Web-Shop

Part No. 961003 DB M MOD 320

GTIN 4013364118607, Customs tariff No. (EU): 853630, Gross weight: 192.00 g, PU: 1.00 件

Images

Additional information

火花间隙保护模块 DB M MOD 320
主电源火花间隙保护模块，
用于 Red/Line 产品系列中符合 EN 61643-11 标准的协调 1 型电涌保护器

RADAX Flow 续流抑制技术，
可最大程度的提高系统可靠性
最大持续工作电压：320 V AC
雷电冲击电流：50 kA
故障指示

制造商： DEHN
型号: DB M MOD 320
货号: 961003
其他类似产品

Certificates



Wave breaker function

In the case of spark-gap-based type 1 arresters, the entire current flows through the type 1 arrester during the discharge process. Like a wave breaker, the incoming energy is greatly broken down, which significantly relieves the downstream SPDs. All type 1 arresters in the Red/Line product range feature the WBF wave breaker function.

Technical data

交流最大持续工作电压 (UC ) 320
雷电冲击电流(10/350 μs) (Iimp ) 50 kA

Product 961003 was added to Notepad.

Go to Notepad

Product 961003 was added to the cart.

Go to Web-Shop
